透明PET標簽
透明PET標簽 PET標簽印刷 電子,汽車,燈飾行業專用標簽-高賦碼
產品說明書
| 編號: | A-016 | ||||
| 品 名 | 25番透明特多龍 | 代 號 | TLTB-Y22V | 英文名稱 | 25μ TRANSPARENT POLYESTER LABEL |
| ARTICLE NAME | 標簽紙 | CODE | ENGLISH NAME | 25μ TRANSPARENT POLYESTER LABEL | |
| 產品結構 PRODUCTION CONSTRUCTION |  | SURFACE MATERIAL SYNTHETIC RESIN | |||
| 面 材 | SURFACE MATERIAL | 底 紙 | LINER | ||
| 材料名稱 | 聚酯膜 | 材料名稱 | PE淋膜離型紙 | ||
| ARTICLE NAME | POLYESTER FILM | ARTICLE NAME | PE LAMI RELEASE | ||
| 厚度 | 0.023±0.005 | 厚度 | 0.155±0.008 | ||
| THICKNESS | THICKNESS | ||||
| 基重(g/m2) | 32±5 | 基重(g/m2) | 140±5 | ||
| BASIC WEIGHT | BASIC WEIGHT | ||||
| 顏色 | 透明 | 顏色 | 黃色 | ||
| COLOR | TRANSPARENT | COLOR | YELLOW | ||
| 平滑度 | GOOD | 平滑度 | GOOD | ||
| SMOOTHNESS | SMOOTHNESS | ||||
| 印刷性 | GOOD | 斬性 | GOOD | ||
| PRINT ABILITY | DIE CUTTING | ||||
| 粘 膠 PRESSURE SENSITIVE ADHESIVE | |||||
| 膠系 | 壓克力 | 剝離力（gf/inch) | 6±3 | ||
| ADHESIVE | ACRYLIC | RELEASE FORCE | |||
| 上膠厚度 | 0.020±0.003 | 保持力 | 1↑ | ||
| THICKNESS | (hr/kg×inch) HOLDING POWER | ||||
| 上膠量(g/m2) | 20±3 | 耐候性 | GOOD | ||
| DRY COATING WEIGHT | WEATHER RESISTANCE | ||||
| 加熱減量(wt%) |
2.0 | 適用溫度(。C) | -5 -100 | ||
| SOVLENT RETENTION | TEMPERATURE RANGE | ||||
| 初期力 | 4 | 耐溶劑 | |||
| (NO/BALL) INITIAL TACK | SOLVENT RESISTANCE | ||||
| 粘著力(kgf/inch) | 0.4 ↑ | ||||
| 180。PEELADHESIVE | |||||
| 備 注： | 以上諸項技術資料乃本公司采用公認可靠之檢驗方法，經多次檢驗所得平均數據，但為確保正確 |
| 選擇與使用本公司之產品，請您基于欲使用之對象，先行對使用目的與條件作詳盡了解與試用， | |
| 或通知本公司，以便為您更進一步說明與服務。 | |
| REMARK： | THE TECHNIAL DATA ARE BASED ON THE RELIABLE EXPERIMENT CARRIED BY THE |
| COMPANY。WHICH HOWEVER ARE NOT TO GAURANTEE THOSE PROPERTIES AND | |
| CHARACTERISTICS COMPLETELY AS SPECIFIED THEREIN，KINDLY STUDY YOUR PURPOSE | |
| AND CONDITION TO USE THIS PRODUCT PREVIOUSLY IN DETAIL UPON YOUR OWN | |
| RESPONSIBILTTY。 |
